PASUP125UFR-8NW

PASUP125UFR-8NW

PAS recessed floor light, LED 8W 4000K, Ø125mm, body alu,cover stainless steel
Product inquiry

Technical data

Colour of light:WhiteColour rendering index (CRI/Ra):80-89
Colour temperature:4000 KDegree of protection (IP):IP67
Drive-over:yesHeight/depth:58 mm
Impact resistance (IK rating):IK10Light distribution:Symmetric
Light distributor:DiffuserLight source included:yes
Max. load:2000Max. system power:8 W
Nominal voltage:230 VOuter diameter:125 mm
Protection class:IRated luminous flux:347 lm
Recess height/depth:70Reflector:None
Voltage type:ACWith dimming function:yes

Downloads

Product information

  • Catalog page

Images

Photometric data

  • Photometric data LDT
Tender text

Accessories

Z-VERIP-L2

2 way connector

Z-VERIP-DLH2O

3/4 way connector
